DJI Ronin SC Gimbal Stabilizer - Professional Combo


PERIPHERAL

Accessory Connections1/4” Mounting Hole, 3/8” Mounting Hole, Camera Control Port, Accessory Port, USB-C Port, RSA Port
Intelligent BatteryModel: RB2-2450mAh-7.2V
Type: 18650 LiPo
Capacity: 2450 mAh
Power: 17.64 Wh
Max. Battery Life: 11 h
Charging Time: 2.5 h (5 V/2 A)
Charging Temperature: 5° to 40°C (41° to 104°F)
ConnectionsBluetooth 5.0; USB-C
Mobile Assistant Software RequirementsiOS 9 or above; Android 5.0 or above

MECHANICAL & ELECTRICAL CHARACTERISTICS

Working CurrentStatic current: 0.2 A
Working Frequency2.400 GHz to 2.4835 GHz
Transmission Power≤ 8 dBm
Operating Temperature-20° to 45°C (-4° to 113°F)
WeightGimbal: Approx. 830 g
BG18 Grip: Approx. 258 g
Tripod: Approx. 160 g
Gimbal DimensionsFolded: 220×200×75 mm
Unfolded: 370×165×150 mm

WORKING PERFORMANCE

Tested Payload≤ 2.0 kg
Angular Vibration Range±0.02°
Maximum Controlled Rotation SpeedPan axis control: 180°/s
Tilt axis control: 180°/s
Roll axis control: 180°/s
Mechanical Endpoint RangePan axis control: 360° continuous rotation
Tilt axis control: -202.5° to +112.5°
Roll axis control: -95° to +220
Controlled Rotation RangePan axis control: 360° continuous rotation
Tilt axis control: -90° to 145°
Roll axis control: ±30°
Includes/Requires:
Includes:
