   Electric (Brushless) Motors & Accessories Electric Brushless Motors - Outrunner HL Q2 2212 / 920KV 3-4S Outrunner Brushless Motors CW/ CCW Set
   Multi-rotors Motors
SKU:  Q2-920
Browse HL
HL Q2 2212 / 920KV 3-4S Outrunner Brushless Motors CW/ CCW Set
Customers rating.
Add To Wish List
Added:2015/01/27
Updated:2017/09/22

Follow Us on:


  Tags: multi-rotor  brushless motor  hengli HL Q Series

  Specifications:

HL Q2 2212 / 920KV 3-4S Outrunner Brushless Motors CW/ CCW Set

KV: 920KV
Net weight: 52g
Stator size: 23 x 12mm
Motor size: Φ28 x 28mm
Idle current: 0.75A @10V
Cell number supported: 3-4S Lipo
Max continuous current: 22A
Max continuous power: 260W
Internal resistance: 0.132Ω




  Includes/Requires:
Includes:
2 x motors ( 1 x CW; 1x CCW)
2 x M6 prop adaptors
2 x M5 prop adaptors
1 x screw bag
