FEATURES

     These speed controllers are designed for use in aircraft models such as indoor flyer, slow flyer, park flyers and gliders operating with brushed electric motors. They feature "soft start", which enables the speed controller to also be suitable for motors that are equipped with a gearbox. The speed controllers adopt MCU decoder, not hardware as do some other brands of speed controller.The Blue Arrow speed controllers have extremely fine resolution, with 1024 steps from OFF to FULL throttle. This resolution gives the ESC an incredibly smooth throttle response.

Name	Size	Net weight (Exclude package and wire)	Weight	Auto-Cutoff Voltage	Current limiting
PP-3A	18mmX12mmX6mm (0.71inx0.47inx0.24in)	1.6g(0.06oz)	6.6g(0.24oz)	4.2V(5-8cellsNi-MH)	3A
PP-3B	18mmX12mmX6mm (0.71inx0.47inx0.24in)	1.6g(0.06oz)	6.6g(0.24oz)	6V(2cellsLi-Poly)	3A
PP-3C	18mmX12mmX6mm (0.71inx0.47inx0.24in)	1.6g(0.06oz)	6.6g(0.24oz)	9V(3cellsLi-Poly)	3A
PP-5A	18mmX12mmX6mm (0.71inx0.47inx0.24in)	1.6g(0.06oz)	6.6g(0.24oz)	4.2V(5-8cellsNi-MH)	5A
PP-5B	18mmX12mmX6mm (0.71inx0.47inx0.24in)	1.6g(0.06oz)	6.6g(0.24oz)	6V(2cellsLi-Poly)	5A
PP-5C	18mmX12mmX6mm (0.71inx0.47inx0.24in)	1.6g(0.06oz)	6.6g(0.24oz)	9V(3cellsLi-Poly)	5A
PP-8A	18mmX14mmX8mm (0.71inx0.55inx0.32in)	1.8g(0.06oz)	12.7g(0.45oz)	4.2V(5-8cellsNi-MH)	8A
PP-8B	18mmX14mmX8mm (0.71inx0.55inx0.32in)	1.8g(0.06oz)	12.7g(0.45oz)	6V(2cellsLi-Poly)	8A
PP-8C	18mmX14mmX8mm (0.71inx0.55inx0.32in)	1.8g(0.06oz)	12.7g(0.45oz)	9V(3cellsLi-Poly)	8A
PP-10A	18mmX14mmX8mm (0.71inx0.55inx0.32in)	1.8g(0.07oz)	12.7g(0.45oz)	4.2V(5-8cellsNi-MH)	10A
PP-10B	18mmX14mmX8mm (0.71inx0.55inx0.32in)	1.8g(0.07oz)	12.7g(0.45oz)	6V(2cellsLi-Poly)	10A
PP-10C	18mmX14mmX8mm (0.71inx0.55inx0.32in)	1.8g(0.07oz)	12.7g(0.45oz)	9V(3cellsLi-Poly)	10A
PP-15A	34mmX24mmX10mm (1.36inx0.96inx0.40in)	3.9g(0.14oz)	17.8g(0.62oz)	4.2V(5-8cellsNi-MH)	15A
PP-15B	34mmX24mmX10mm (1.36inx0.96inx0.40in)	3.9g(0.14oz)	17.8g(0.62oz)	6V(2cellsLi-Poly)	15A
PP-15C	34mmX24mmX10mm (1.36inx0.96inx0.40in)	3.9g(0.14oz)	17.8g(0.62oz)	9V(3cellsLi-Poly)	15A
PP-20A	34mmX24mmX10mm (1.36inx0.96inx0.40in)	3.9g(0.14oz)	17.8g(0.62oz)	4.2V(5-8cellsNi-MH)	20A
PP-20B	34mmX24mmX10mm (1.36inx0.96inx0.40in)	3.9g(0.14oz)	17.8g(0.62oz)	6V(2cellsLi-Poly)	20A
PP-20C	34mmX24mmX10mm (1.36inx0.96inx0.40in)	3.9g(0.14oz)	17.8g(0.62oz)	9V(3cellsLi-Poly)	20A
PP-25A	34mmX24mmX10mm (1.36inx0.96inx0.40in)	4g(0.15oz)	18g(0.63oz)	4.2V(5-8cellsNi-MH)	25A
PP-25B	34mmX24mmX10mm (1.36inx0.96inx0.40in)	4g(0.15oz)	18g(0.63oz)	6V(2cellsLi-Poly)	25A
PP-25C	34mmX24mmX10mm (1.36inx0.96inx0.40in)	4g(0.15oz)	18g(0.63oz)	9V(3cellsLi-Poly)	25A
PP-30A	34mmX24mmX10mm (1.36inx0.96inx0.40in)	4g(0.15oz)	18g(0.63oz)	4.2V(5-8cellsNi-MH)	30A
PP-30B	34mmX24mmX10mm (1.36inx0.96inx0.40in)	4g(0.15oz)	18g(0.63oz)	6V(2cellsLi-Poly)	30A
PP-30C	34mmX24mmX10mm (1.36inx0.96inx0.40in)	4g(0.15oz)	18g(0.63oz)	9V(3cellsLi-Poly)	30A
