T-Motor Navigator Series MN3508 700KV Outrunner Brushless Motor for Multi-copter (3-4S)
Customers rating.
Add To Wish List
Added:2013/09/12
Updated:2013/11/28
Follow Us on:


  Tags: multi-rotor  brushless motor  T-motor

Specifications:

T-Motor Navigator Series MN3508 700KV Outrunner Brushless Motor  for  Multi-copter  (3-4S)
Specifications:
KV...............................................................................................................700
Configu ration..................................................................................12N14P
Stator Diameter..................................................................................35mm
Stator Length........................................................................................8mm
Shaft Diameter.....................................................................................4mm
Motor Dimensions(Dia.*Len).........................................Φ41.8×26.5mm
Weight (g)................................................................................................82g
ldle current(10)@10v(A).......................................................................0.5A
No.of Cells(Lipo)..................................................................................3-4S
Max Continuous current(A)180S.........................................................23A
Max Continuous Power(W)180S.....................................................510W
Max. efficiency current..............................................................(3-9A)>80%
internal resistance.............................................................................72mΩ

\















Includes/Requires:
Includes:
1 x motor
1 x prop adaptor
1 x prop holding down plate for direct mounting
1 x screws bag
