| SKU | 2316SL-14 |
|---|---|
| Brand | HOBBYWING |
| Added | 2024/03/06 |
| Updated | 2024/03/06 |
Specifications:
Hobbywing SKYWALKER 2316SL 1400KV Airplane Brushless Motor
Manufacturer code: 30415052
Recommended Battery: 3-4S LiPO
KV: 1400KV
No-load Current: 2.3A/ 14.8V
Internal resistance: 28.4mΩ
Maximum continuous current: 42A/ 135s
Maximum continuous power: 618W/ 135s
Motor Size: Φ28.8 x 50mm
Shaft Diameter: 4mm
Clip mounting hole thread: Φ12mm-3xM2.5
Base thread: Φ16mm-2xM3/Φ19mm-2xM3
Motor Weight: 79g
Recommend configuration (not included):
ESC: Skywalker-V2 40A - 50A
propeller: 3S: 7x6E，8x6E; 4S：7x5E，8x4E
Recommended Battery: 3-4S LiPO
KV: 1400KV
No-load Current: 2.3A/ 14.8V
Internal resistance: 28.4mΩ
Maximum continuous current: 42A/ 135s
Maximum continuous power: 618W/ 135s
Motor Size: Φ28.8 x 50mm
Shaft Diameter: 4mm
Clip mounting hole thread: Φ12mm-3xM2.5
Base thread: Φ16mm-2xM3/Φ19mm-2xM3
Motor Weight: 79g
Recommend configuration (not included):
ESC: Skywalker-V2 40A - 50A
propeller: 3S: 7x6E，8x6E; 4S：7x5E，8x4E
Includes/Requires:
Includes:1 x motor Skywalker 2316SL
1 x accessory bag
