Hobbywing SKYWALKER 2826SL 540KV Airplane Brushless Motor
    SKU 2826SL-54
    Brand HOBBYWING
    Added 2024/08/02
    Updated 2024/08/02

    Tags: Hobbywing_SKYWALKER_2826SL_540KV_Airplane_Brushless_Motor

    Specifications:

    Hobbywing SKYWALKER 2826SL 540KV Airplane Brushless Motor


    Manufacturer code: 30415250
    Recommended Battery: 6S LiPO
    KV: 540KV
    No-load Current: 1.58A/22.2V
    Internal resistance: 43.9mΩ
    Number of slot poles: 12N14P
    Maximum continuous current: 49.7A/ 60s
    Maximum continuous power: 1106.5W/1min
    Motor Size: Φ35.1 *66mm
    Shaft Diameter: 5mm
    Bearing model: 685ZZ(D11*d5*5)
    Phase cable: 16AWG
    Cable Length: 110mm
    Base thread: Φ16mm-2xM3/Φ19mm-2xM3
    Motor Weight: 175.5g

    Recommend configuration (not included):
    ESC: Skywalker 80A
    propeller: 6S:12x6E,13x6.5E,14X6
    Clip mounting hole thread: Φ15mm-3*M2.5
    Base thread: Φ19mm-2*M3/Φ25mm-2*M3


    Includes/Requires:

    Includes:
    1 x motor Skywalker 2826SL
    1 x accessory bag
