10 inch 1024x600 Resolution Field Monitor W/Sunlight Shield FPV-101AH-450

SKU: FV101A

10 inch 1024x600 Resolution Field Monitor W/Sunlight Shield FPV-101AH-450

Added:2013/06/04
Updated:2013/06/04

Features:

Overview: This series monitors are ideal Monitors for FPV or aerophotography.Designed specially for FPV and outdoor operation purpose. The monitor has very bright image(adjustable)and very wide power supply range(7-12V). It also has a very important feature for FPV users, it doesn't have "blue screen" problem when the signal gets weak. This feature makes you able to fly much further and never lose image. When VTX is not connected ,it just show static, never turn blue or black.

Specifications:

10" 1024x600 Resolution Field Monitor W/Sunlight Shield FPV-101AH-450

Specification
Desciption	10.1" Ground Station FPV HD Monitor
Model:	FPV-101AH
Brightness:	450cd/m² New Brighter Version
Physical Resolution:	1024*600pixels
Contrast Ratio:	500:1
Aspect Ratio:	16:9
Backlight:	LED
Viewing Angle:	70°/70°(L/R) 40°/50°U/D
Input Voltage:	DC 7-12V
Input Signal:	HDMI, VGA, AV1, AV2, Audio, YPbPr
FPV Signal	AV2 Designed for FPV(No Blue Screen)
Mounting Process	1/4-20 Thread Hole in the bottom
Power Consumption:	≦10W
WorkTemperature:	-20℃～60℃
Store Temperature:	-30℃～70℃
Unit Size:	255L163W 34.3H mm
Unit Weight:	560g
Certificate	CE, FCC, Rohs
Standard Accessory	DC12V Power Supply, Sun Shield,VGA Cable,AV Cable, Remote Contronller

Includes/Requires:

Includes:
1 x monitor
1 x sunlight shield
1 x 12V AC adaptor
1 x remote control
1 x A/V cable
1 x manual
