   FPV/ Aerial Photography Flight Controller/OSD/ GPS/ Stablizer DJI iOSD Mark II on screen display FPV Autopilot Display System
SKU:  DJIOSD
Browse DJI
DJI iOSD Mark II on screen display FPV Autopilot Display System
Customers rating.
Add To Wish List
Added:2015/04/20
Updated:2015/05/08
Follow Us on:



  Tags: DJI iOSD Mark II on screen display FPV Autopilot Display System

Features:
Real-Time Accurate Flight Data & Video Signal Superposition
TheDJI iOSD MARK II can collect real-time video and flight data, which will help you to obtain the aircraft status information during flight. It can display power voltage, flight velocity, height, distance from the home point,horizontal attitude and GPS satellite number, etc.

iOSD MARK II Features
Highly integrated, beautiful and practical, compact size
Support DJI professional autopilot system
Real-time accurate flight data & video signal superposition
Supportdouble video source input, switchable during flight
Remotevideo link channels in real-time switch
FlightLog Function
FreeUpgradable Online
Built-inBEC module, support 3s-6s LiPo
User-friendly Assistant Software
Specifications:

DJI iOSD Mark II on screen display FPV Autopilot Display System

Size and Weight

 spec

Performance Parameter
Video Input Model
PAL/NTSC
Video Output Model
PAL/NTSC

Physical Parameter
Temperature
-20℃~60℃
Size
52mm X 41mm X 11mm
Weight
56g

Hardware Supported
Voltage
3S~6S
Current(Typical Value)
60mA@25.2V
103mA@12.6V
Rated Power
1.25W
Controller Supported
A2
WKM
Naza-M
Naza-M V2

Software Supported
Build-In Function
1.iOSD Information Transmission
2.Video Transmission, Two Video Signal Channels Input & Switch
3.Channel Switch Supported for the Wireless Video Transmitter Module specified by DJI
4.DJI Z15 Supported
Includes/Requires:
Includes:
1 x DJI iOSD Mark II
