Uni-Trend is one of the leading testing meters and instruments companies in Asia. It is also a prestige
brand of testing meter industry in China.

SPECIFICATIONS

Basic Functions	Range	Best Accuracy
DC Voltage	200mV/2000mV/20V/200V/500V	(0.5%+2)
AC Voltage	200V/500V	(1.2%+10)
DC Current	2000mA/20mA/200mA/10A	(1%+2)
Resistance	200W/2000W/20kW/200kW/20MW/200MW	(0.8%+2)
Special Functions
Diode
Continuity Buzzer
Square Wave Output
Data Hold
Display Backlight
Low Battery Display
Input Impedance for DC Voltage Measurement	Around 10MW
Max. Display	1999

GENERAL CHARACTERISTICS

Power	9V Battery (6F22) (not included)
LCD Size	48 x 16mm
Product Colour	Red and Grey
Product Net Weight	156g
Product Size	130 x 73.5 x 35mm
Standard Accessories	Test Lead, Battery, English Manual, Holster
Standard Individual Packing	Gift Box
Standard Quantity Per Carton	60pcs
Standard Carton Measurement	490 x 356 x 315mm (Around 0.055 CBM Per Standard Carton)
Standard Carton Gross Weight	18kg

Specifications and other information are subject to change without further notice.

* MAKE SURE THE CORRECT MODE AND RANGE IS SELECTED DURING TESTING, DAMAGE DUE TO WRONG MODE OR WRONG RANGE IS NOT COVERED BY WARRANTY.
* WHEN MEASURE CAPACITORS, MAKE SURE THE CAPACITORS ARE DISCHARGED (CAN BE DONE BY SHORT CIRCUIT THE TWO LEGS OF THE CAPACITORS), FAILURE SO MAY CAUSE DAMAGE TO THE MULTI-METER.

Includes:
1 x multimeter
1 x test lead

Requires:
1 x 9V battery (6F22 or alike)

* The printed manual is in Chinese, please download the English manual here .
