   Electric (Brushless) Motors & Accessories Electric Brushless Motors - Outrunner EdgeRacing 2206 2480KV Competition/ Racing Class Brushless Motor CW
   Multi-rotors Motors
SKU:  EG2224CW
EdgeRacing 2206 2480KV Competition/ Racing Class Brushless Motor CW
Customers rating.
Add To Wish List
Added:2016/05/27
Updated:2016/07/08
Follow Us on:


  Tags: EdgeRacing Competition/ Racing Class Brushless Motor

Specifications:

EdgeRacing 2206 2480KV Competition/ Racing Class Brushless Motor CW


Stator Diameter22mm
Stator Thickness6mm
No.of Stator Arms12
No.of Stator Poles14
Motor Kv2480
NO-Load Current(A/10V)0.7
Motor Resistance43mΩ
Max Continuous Current28A/10S
Max Continuous Power415W
Weight34g
Outside Diameter27mm
Shaft Diameter5mm
Body Length20.3mm
Overall Shaft Length33.3mm
Max Lipo Cell3-4S
ESC30A-40A
Recommend Prop(inch)5030/ 5040/ 5045

PropVoltsAmps Thrust(g)Watts (W)Efficiency
(g/W)
Full throttle Temperature (environment temp. 25℃)
(inch)(V)(A)
HQ5*311.11.710018.875.30
2.715029.975.01
3.820042.184.74
5.125056.614.42
6.430071.044.22
7.635084.364.15
940099.94.00
10.3450114.333.94
11.7500129.873.85
12.4520137.643.7830℃
HQ5*314.81.310019.245.20
2.215032.564.61
3.320048.844.10
4.225062.164.02
5.230076.963.90
6.235091.763.81
7.3400108.043.70
8.6450127.283.54
9.8500145.043.45
11550162.83.38
12.3600182.043.30
13.6650201.283.23
14.9700220.523.17
16.5750244.23.07
18.3800270.842.95
19.2830284.162.9238℃
HQ5*411.11.710018.875.30
2.915032.194.66
4.120045.514.39
5.325058.834.25
6.830075.483.97
8.335092.133.80
9.8400108.783.68
11.4450126.543.56
12.9500143.193.49
14.6550162.063.39
16.3600180.933.32
18.3650203.133.2035℃
HQ5*414.81.510022.24.50
3.420050.323.97
5.630082.883.62
8.1400119.883.34
11.2500165.763.02
13.5600199.83.00
17700251.62.78
20.5800303.42.64
24.1900356.682.52
27.4960405.522.3753℃
HQ5*4.511.11.910021.094.74
315033.34.50
4.320047.734.19
5.625062.164.02
730077.73.86
8.635095.463.67
10.1400112.113.57
11.8450130.983.44
13.1500145.413.44
14.8550164.283.35
16.6600184.263.26
18.8660208.683.1637℃
HQ5*4.514.81.510022.24.50
3.420050.323.97
5.530081.43.69
8400118.43.38
11.3500167.242.99
13.5600199.83.00
17.1700253.082.77
20.6800304.882.62
24.2900358.162.51
27.59604072.3653℃

Includes/Requires:
Includes:
1 x  brushless motor
