Extremely Low Resistance (.0013 ohms)
High Rate Adjustable Switching (PWM)
Up to 60 Amps Continuous Current with Proper Air Flow,
80 Amp Surge
Five to Ten Cells with Four Micro Servos
Up to Twelve Cells with Three Micro Servos
Twenty Cells Max (With BEC Disabled)
Dynamic Braking Ensures Folding Props Fold Promptly
BEC (3A) Provides Power to Reciever and Servos
User Programmable Features:
Low Voltage Cutoff
Over Current Protection
Brake Type
Throttle Range-Fixed/Self Adjusting/Governor
Timing Advance
Cutoff Type
Soft Start Ramp Up
Switching Frequency
Runs Motor in Forward or Reverse
Auto Motor Cutoff with Reset
Safe "Power On" arming program ensures motor will not
accidentally turn on
Low Torque "Soft Start" Prevents Damage to Fragile Gearboxes
Auto Shut Down When Signal is Lost or Radio interference
becomes severe
13 gauge battery and motor wires

Width: 1.05" (27mm)
Height: .45" (11mm)
Length: 2.35 (60mm)
Weight: 2oz (58g) with wires
Input Voltage: 5-12C w/BEC
5-20C Max w/BEC Disabled
Max Rated Current: 60 Amps continous max w/proper airflow
On Resistance: 0.0012 Ohms
Low Voltage Cutoff: Programmable
Connectors: Universal RX Connector. No Battery Connector.
Switching Rate: Programmable (11khz, 22khz, or 41khz)
Servo Ratings with BEC Enabled:
Servo Type: 5-6C: 7-8C: 9-10C: 11-12C:
Standard Micro 5 Servos 5 Servos 4 Servos 3 Servos
High Torque 4 Servos 4 Servos 3 Servos 2 Servos

Click here for User Manual
