SUNNYSKY A2218 2000KV Outrunner Brushless Motor for 450 Class Helicopter

SUNNYSKY A2218 2000KV Outrunner Brushless Motor for 450 Class Helicopter

KV 2000
Configu-ration 9N6P
Stator Diameter 22mm
STator Length 18mm
Shaft Diameter 3.17mm
Motor Dimension(Dia.﹡Len) Φ27.7×35mm
Weight(g) 67
ldle current(10)@10v(A) 1.0
No.of Cells(Lipo) 6S
Max Continuous current(A)180S 25A
Max Continuous Power(W)180S 400
Max Continuous Power(W)15s 550
Max. efficiency current (15-22A)>73%
internal resistance 55mΩ
Recommended Gear 11T/12T
Esc Requirement 30A&45A
