Hobbywing XRotor 2807 900KV FPV Brushless Motor

Specifications

Product Number	30418000	30418001	30418002
KV Rating	1300KV	1500KV	1700KV
LiPo Cells（LiPo）	4-6S	4-5S	3-4S
No-Load Current	2A/24V	2.27A/20V	2.13A/16V
Maximum Continuous Current	56.7A/6s	59.5A/7s	53.9A/13s
Maximum Continuous Rating	1361W/6s	1195W/7s	864W/13s
Maximum Thrust	2818g	2646g	2205g
Motor Weight	59g	58.7g	58.4g
Motor Size	Φ34x20.5mm	Φ34x20.5mm	Φ34x20.5mm
Slot/Pole	12N14P	12N14P	12N14P
Wire Size	18AWG	18AWG	18AWG
Wire Length	200mm	200mm	200mm
Enamelled Wire Insulation Class	220℃ High temperature Resistant, H Class insulation	220℃ High temperature Resistant, H Class insulation	220℃ High temperature Resistant, H Class insulation
Internal Resistance	53.8mΩ	43.6mΩ	37.5mΩ
Shaft Diameter	D5+M5	D5+M5	D5+M5
Shaft Length	15mm	15mm	15mm
Screw Diameter / Thread	Φ19mm-4xM3	Φ19mm-4xM3	Φ19mm-4xM3

Recommended
Props/ESCs

Recommended ESC	XRotor FPV G2 65A 4in1 ESC	XRotor FPV G2 65A 4in1 ESC	XRotor FPV G2 65A 4in1 ESC
Propeller	4-6S:HQ7x3.5x3; HQ7x4x3	4-5S:HQ7x3.5x3; HQ7x4x3	3-4S:HQ7x3.5x3; HQ7x4x3

Includes:

1 x motor Hobbywing XRotor 2807 900KV
