LEOPARD 68mm Aluminum Ducted fan W/2550KV 4-pole motor L68EDF-6B1

THIS IS THE HIGH END METAL Ducted fan FROM LEOPARD FOR HIGH END APPLICATION.

- Aluminum duct.
- 4-pole brushless motor
- High efficiency, less heat productivity
- Motor seat incorporated with duct, heat radiation much improved.
- Air flow guiding trunk for motor wires.
- Strong thrust
- Minimal vibration
- High power

Type: L68EDF-6B1

Leopard Ducted Fan Series(EDF)
Model	Rotor size	Lipo Cell	MAX RPM	Max power (w)	Voltage	Current	Efficiency (g/W)	Thrust (Kg)	Thrust Up to (Kg)	innerdia×outerdia× Length EDF(mm)	Weight
L65EDF-3A1	Ф65	3S	50000	800	12V	45A	1.72	1.33	1.4	66×69×45	200g
L68EDF-3B1	Ф68	3S	50000	1000	12V	61A	1.82	1.33	1.4	68×72×50	250g
L68EDF-4B1	Ф68	4S	50000	1000	14.8V	62A	1.66	1.52	1.6	68×72×50	250g
L68EDF-6B1	Ф68	6S	50000	1300	23V	50A	1.66	1.91	2.0	68×72×50	280g
L90EDF-6B1	Ф90	6S	45000	2200	23V	78A	1.76	3.15	3.3	89×94×70	560g
L90EDF-8B1	Ф90	8S	45000	2800	30V	50A	1.97	2.95	3.1	89×94×70	560g
		9S			34V	63A	1.71	3.67	3.8
		10S			37.5V	73A	1.57	4.30	4.4

Includes:
1 x Ducted fan
1 x Brushless motor
3 x bullet connectors
