   Airplanes Airplane Accessories - Ducted Fan ( EDF ) SAPAC/GlobalFly EDF 70 Ducted fan W/2842-3200KV Brushless motor
SKU:  ED7032
SAPAC/GlobalFly EDF 70 Ducted fan W/2842-3200KV Brushless motor
Customers rating.
Add To Wish List
Bookmark and Share
Added:2010/04/07
Updated:2011/10/28
Follow Us on:

2E9D97913328


PRICE(USD):
    $33.97   Discontinued  Suggesting Restock
Member PRICE:
    Sign in or Sign up for member price

  Tags: 70mm  electric ducted fan  EDF

Specifications:
Inner diameter of Duct: 70mm
Duct length: 77mm
Length of motor with tail cone: 115mm
Weight: 221g(with tail cone and motor)
Fitting Motor: 28mm grade OD. Diameter of Axle 4mm, outrunner motor
Rotor Blade: High tensile and high precision 5 blade rotor
Max RPM of Rotor Blade: 50000 RPM

Motor specs:
Size: Φ28.5 x 68mm
Max lock-rotor current: 75A
Shaft diameter: Φ4mm
None-load current: 2.8A ±0.2A
Weight: 110g
Resistance(mΩ): 15.0
Power: 417W
Thrust: 935g
KV: 3200
Battery: 3S
Recommended model weight: 800-1100g

* The manufacturer uses two brands for this EDF, you may see some time it branded as GLOBAL FLY on the packing, yet some time it branded as SAPAC, I confirm they are identical in specs and quality except the packing box.
Includes/Requires:
Includes:
1 x Ducted fan
1 x outrunner Brushless motor (pre-installed)
1 x tail cone
Comments:
Customer contributed testing result (for reference only):
under 3S lipo: 34A, 1200g thrust
under 4S Lipo: 56A, 1700g thrust
Customer Reviews:
Average Customer Review: 5 stars   3 customer review(s).   [Write a review/question]

e****771
Grade:
This is the MB1 WITH the fan for less than 40USD!!!

You're not going to find this price anywhere.

My test on this fan motor combo

4s 60amps (settled) 53oz thrust
5s 80amps (settled) 73oz thrust (motor warm not hot)

Some have tested a 3200kv motor (not the MB1) on a wemo (wemo copy sold here) and have gotten 6pds of thrust on 6s but I believe the MB1 can handle it cause it's an outrunner.

I've run the MB1 (included in this fan) up to 110 amps for 5 seconds and it gets VERY hot to the touch so it'll need a cool down after run
January 20 2011     Was this review helpful to you?   Yes [ 2 ]   No [ 0 ]    [Reply this review]

j****234567
Grade:
on 4S 30C lipo I got 883Watts at 62Amps
August 23 2010     Was this review helpful to you?   Yes [ 1 ]   No [ 0 ]    [Reply this review]

Y****HOBBYSHOP
Grade:
PLEASE MAKE SURE MY ORDER S HAVE ALL OUTRUNNER MOTORS ONLY
April 27 2010     Was this review helpful to you?   Yes [ 0 ]   No [ 0 ]    [Reply this review]
