Hobbywing SKYWALKER 2826SL 1100KV Airplane Brushless Motor

Lithium Polymer (Li-poly) & Ni-Mh battery packs, battery chargers, Electric (Brushless) Motors, Electric Speed Controllers ( ESC ), Gyros, Electric Accessories etc.

Electric

(Brushless) Motors & Accessories

Electric Brushless Motors - Outrunner

Manufacturer code: 30415252
Recommended Battery: 3-4S LIPO
KV: 1100KV
No-load Current: 3.7A/14.8V
Internal resistance: 14.08mΩ
Number of slot poles: 12N14P
Maximum continuous current: 82.4A/2min15s
Maximum continuous power: 1218.9W/2min15s
Motor Size: Φ35.1 *66mm
Shaft Diameter: 5mm
Bearing model: 685ZZ（D11*d5*5）
Phase cable: 16AWG
Cable Length: 110mm
Base thread: Φ16mm-2xM3/Φ19mm-2xM3
Motor Weight: 175.8g

Recommend configuration (not included):
ESC: Skywalker 80A
propeller:
4S：10x5E，11x5.5E
3S:11x5.5E，12x6E,13x6.5E
Clip mounting hole thread: Φ15mm-3*M2.5
Base thread: Φ19mm-2*M3/Φ25mm-2*M3

Includes:
1 x motor Skywalker 2826SL
1 x accessory bag
